IEC 60745-2-5 Test Probe For Circular Saw Guard Diameter 12mm Length 50mm

Brand Name:	HongCe
Model Number:	HDD8301
MOQ:	1 set
Price:	Negotiatable
Payment Terms:	T/T
Supply Ability:	100 set /month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Calibrate Certificate (Cost Additional )

Standard:

IEC 60745-2-5, Clause 19.101.2 And Figure 105

Test Sample:

Circular Saws

Probe Diameter:

12mm

Probe Length:

50mm

Baffle Diameter:

35mm

Baffle Thickness:

5mm

Handle Diameter:

8mm

Handle Length:

30mm

Packaging Details:

Aluminum box

Highlight:

IEC 60745-2-5 Test Probe

Circular Saw Guard Test Probe

Length 50mm Test Probe

Product Description

IEC 60745-2-5 Test Probe a for Circular Saw Guard Test, diameter 12mm, length 50mm

Standard: IEC 60745-2-5 : Particular requirements for circular saws, clause 19.101.2 and Figure 105

Application: This probe is applicable to verify the upper guard protection against to touch the blade.

Test sample: Circular saws Test Finger Probe

Feature: Apertures in the guarding system above the guide plate, unless otherwise specified below, shall be designed such that the test probe ‘a’ of figure 105, when inserted at any angle and to the depth allowed by its stop, shall not be able to contact the cutting edge zone of any recommended blade. Test Finger Probe

Parameters:

1. Probe: diameter 12mm, length 50mm, R6 hemisphere end

2. Stop: diameter 35mm, thickness 5mm

3. Handle: diameter 8mm, length 30mm Test Finger Probe

Probe diameter	12mm
Probe length	50mm
Baffle diameter	35mm
Baffle thickness	5mm
Handle diameter	8mm
Handle length	30mm Test Finger Probe

Picture for reference:

IEC 60745-2-5 Test Probe For Circular Saw Guard Diameter 12mm Length 50mm 0

IEC 60745-2-5 Test Probe For Circular Saw Guard Diameter 12mm Length 50mm 1

IEC 60745-2-5 Test Probe For Circular Saw Guard Diameter 12mm Length 50mm 2
