PLC Current - Carrying Hoses Flexing Resistance Tester 10r / Min Flexing Speed

PLC Current - Carrying Hoses Flexing Resistance Tester 10r / Min Flexing Speed

Brand Name:	HongCe
Model Number:	HJ0616
MOQ:	1 set
Price:	Negotiatable
Payment Terms:	T/T
Supply Ability:	10 Sets per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Calibration Certificate(cost additional)

Usage:

Flexing Resistance Test

Standard:

IEC60335-2-2

Warranty:

1 Year

Application:

Current-Carrying Hoses

Flexing Angle:

40°±1°, Can Be Preset

Flexing Speed:

10r/min (that Is 60°/s)

Mass Weight:

5 Kg

Swing Arm Length:

300mm±50mm

Packaging Details:

Plywood

Highlight:

PLC Hoses Flexing Resistance Tester

Current - Carrying Hoses Flexing Resistance Tester

10r / Min Hoses Flexing Resistance Tester

Product Description

IEC60335-2-2 Current-Carrying Hoses Flexing Resistance Tester 10r/min Flexing Speed

Foreword: In practice, some current carrying hoses need to adapt to various environments for continuous expansion and bending. The current carrying hose with poor quality is easy to break after being bent for a certain number of times. Therefore, before the hose leaves the factory, it is very important to test the bending resistance.
This tester has the characteristics of simple structure, convenient detection and good detection effect. It can effectively reflect the bending resistance of current carrying hose and effectively ensure the ex factory quality of products. Electrical Appliance Tester

Standard: This device meets the standard of IEC60335-2-2, clause 21.103 figure 102.

Application: Suitable for the Current-carrying hoses flexing resistance tester.

Test sample: Vacuum cleaner hoses, water suction type cleaning apparatus tube, washing machine water pipe. Electrical Appliance Tester

Feature: The end of the hose intended to be connected to the motorized cleaning head is attached to the pivoting arm of the test equipment shown in Figure 102. The distance between the pivot axis of the arm and the point where the hose enters the rigid part is 300mm±5mm. The arm can be raised from the horizontal position by an angle of 40°±1°. A mass of 5 kg is suspended from the other end of the hose or from a convenient point along the hose so that when the arm is in the horizontal position the mass is supported and there is no tension on the hose.

The mass slides against an inclined plate so that the maximum deflection of the hose is 3°. The arm is raised and lowered by means of a crank that rotates at a speed of 10±1 revolutions per minute. Electrical Appliance Tester

The test is carried out for 2500 revolutions of the crank after which the fixed end of the hose is turned through 90°and the test continued for a further 2500 revolutions. The test is repeated in each of the other two 90°positions.

Parameters:

Power supply	AC220V 50Hz.
Control and operation	PLC intelligent electrical control, touch screen operation
Working station	1 station
Flexing speed	10r/min(that is 60°/s),can be preset
Flexing angle	40°±1°, can be preset
Mass weight	5 kg
Swing arm length	300mm±50mm
Test times Electrical Appliance Tester	0-999999 times, can be preset
Inclined metal plate	The mass slides against an inclined plate so that the maximum deflection of the hose is 3°
Size and weight	1000×500×1100mm,100kg

Standard figure:

Picture for reference:
