Clause 21.101 Current Carrying Hoses Crushing Resistance Tester 1.5kN

Clause 21.101 Current Carrying Hoses Crushing Resistance Tester 1.5kN

Brand Name:	HongCe
Model Number:	HJ0614
MOQ:	1 set
Price:	Negotiatable
Payment Terms:	T/T
Supply Ability:	10 set /month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

calibration certificate (cost additional)

Warranty:

1 Year

Product Name:

Current-Carrying Hoses Crushing Resistance Tester

Usage:

Crushing Resistance Test

Test Sample:

Current-Carrying Hoses

Standard:

IEC60335-2-2

Applied Force:

1.5kN

Pressure Speed:

50±5mm/min

Steel Plate:

10mm*50mm

Packaging Details:

plywood

Highlight:

Current Carrying Hoses Crushing Resistance Tester

1.5kN Hoses Crushing Resistance Tester

Clause 21.101 Hoses Crushing Resistance Tester

Product Description

IEC60335-2-2 clause 21.101 Current-Carrying Hoses Crushing Resistance Tester 1.5kN

Standard: This device meets the standard of IEC60335-2-2, clause 21.101. Electrical Appliance Tester

Application: Suitable for the Current-carrying hoses crushing resistance tester.

Test sample: Vacuum cleaner hoses, water suction type cleaning apparatus tube, washing machine water pipe. Electrical Appliance Tester

Feature: The hose is placed between two parallel steel plates each having a length of 10 mm, a width of 50 mm and the edges of the longer sides rounded with a radius of 1mm. The axis of the hose is positioned at right angles to the longer sides of the plates. The plates are placed at a distance of approximately 350mm from one end of the hose. The steel plates are pressed together at a rate of 50 mm/min±5 mm/min until the applied force is 1.5kN. The force is then released and electric strength test of 16.3 is carried out between the conductors connected together and the saline solution. Electrical Appliance Tester

Parameters:

Power supply	AC220V 50Hz.
Applied force	1.5kN (2kN range)
Pressure speed	50±5mm/min
Steel plate specification	Length of 10 mm, a width of 50 mm and the edges of the longer sides rounded with a radius of 1mm
Sample placement	The plates are placed at a distance of approximately 350mm from one end of the hose
Pressure mode Electrical Appliance Tester	Motor-driven
Size and weight	1000×500×1500mm,200kg

Picture for reference:
