IEC 60068-2-75 / 1450g / Spring Operated Impact Hammer / 0.14-1J / 6 Gears Optional

Brand Name:	HongCe
Model Number:	SH-6
MOQ:	1 set
Price:	Negotiable
Payment Terms:	T/T
Supply Ability:	100 set/ month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Calibration Certificate (cost additional)

Product Name:

Spring Operated Impact Hammer

Warranty:

1 Year

Color:

Silver

Material:

Stainless Steel, Polyamide

Impact Energy:

0.14, 0.2, 0.35, 0.5, 0.7, 1 J

Impact Element Mass:

250g±5g

Application:

Impact Resistance Test

Impact Energy:

6 Adjustable Energy

Packaging Details:

Aluminum box

Highlight:

IEC 60068-2-75 Spring Operated Impact Hammer

6 Gears Spring Operated Impact Hammer

1450g Spring Operated Impact Hammer

Product Description

IEC 60068-2-75 / 1450g/ Spring Operated Impact Hammer/ 0.14-1J / 6 Gears Optional

Standard: IEC 60068-2-63, IEC 60068-2-75 test Ehb, IEC 60335-1, IEC 60598-1, IEC 60950, and IEC 60065

Application: This device is intended to test the impact resistance to shell, operating arm, handle, knob, indicator lights and shades of electrical appliance for household or similar purpose, to verify the safety performance and strength of the product.

Test sample: Shell, operating arm, handle, knob, indicator lights and shades Impact Testing Machine

Feature:

1. The impact hammer is composed of three parts:

A. Shell. Includes housing, impact element guide and release mechanism, and parts fixed on these parts.

B. Impact element. Including the hammer, hammer tail and firing handle.

C. Release cone. Impact Testing Machine

2. Working principle

The hammer generate impact energy by the mass and movement of impact element. When pulling the operating handle, release claw stop at the impact element release point, the hammer spring is pressed, when the compression quantity is different, the spring will release the different energy. For multi energy impact hammer, rotate the end cover to select corresponding impact energy. The impact energy was calibrated on calibration facility before delivery. Impact Testing Machine

Parameters:

Model	SH-6
Impact energy(J)	0.14 and 0.2, 0.35, 0.5, 0.7, 1
Impact element mass	250g±5g
Overall mass	1450g±10g
Material	Stainless steel

Table E.1 – Kinetic energy of striking element

Kinetic energy ( E )

just before impact

Approximate spring compression

with spring constant of

2,75 × 10³ N/m

0,14 ± 0,014

0,20 ± 0,02

0,35 ± 0,03

0,50 ± 0,04

0,70 ± 0,05

1,00 ± 0,05

NOTE – The approximate value of the kinetic energy in joules, just before the impact, can be calculated from the following formula:

E = 0,5 FC × 1 0 ^{– 3}

where

F is the force exerted by the hammer spring, when fully compressed, in newtons;

C is the compression of the hammer spring, in millimetres

The energy stated above is achieved in the horizontal position.

IEC 60068-2-75 / 1450g / Spring Operated Impact Hammer / 0.14-1J / 6 Gears Optional 0
