IEC 60811 Cable Testing Equipment Oxygen Bomb / Air Bomb Aging Tester 200℃ 4MP

IEC 60811 Cable Testing Equipment Oxygen Bomb / Air Bomb Aging Tester 200℃ 4MP

IEC 60811 Cable Testing Equipment Oxygen Bomb / Air Bomb Aging Tester 200℃ 4MP
IEC 60811 Cable Testing Equipment Oxygen Bomb / Air Bomb Aging Tester 200℃ 4MP
IEC 60811 Cable Testing Equipment Oxygen Bomb / Air Bomb Aging Tester 200℃ 4MP
Product Details:
Place of Origin: China
Brand Name: HongCe
Certification: Calibration certificate(cost additional)
Model Number: HJ0606
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Plywood
Delivery Time: 40 days
Payment Terms: T/T
Supply Ability: 10 sets per month
Contact Now
Detailed Product Description
Name: Oxygen Bomb (Air Bomb) Aging Tester Standard: IEC60811, IEC60335
Warranty: 1 Year Maximum Operating Pressure: 4MP
Secure Burst Pressure: 2.7~3.3MP Temperature-controlled Range: Indoor Temperature~200℃
Inside Chamber Dimensions: Diameter 123×Height337mm Inside Chamber Volume: 4000cm³
High Light:

IEC 60811 Cable Testing Equipment

,

4MP Cable Testing Equipment

,

4000cm3 Air Bomb Aging Tester

IEC 60811 Cable Testing Equipment Oxygen Bomb / Air Bomb Aging Tester 200℃ 4MP



IEC60811-1-2 clause 8.3:

Ageing in an oxygen bomb

Test pieces as specified in Clause 9 of I EC Publication 811-1-1 shall be placed in the bomb at room temperature without touching each other. They shall not occupy more than one-tenth of the effective capacity of the bomb.
Compounds of substantially different compositions shall not be tested at the same time.
The bomb shall be filled with commercial oxygen of not less than 97% purity to a pressure of 2.1 ± 0.07 MPa.
The test pieces shall be kept in the bomb at the temperature and for the time specified for the material in the standard for the type of cable.
As soon as the ageing period is completed, the pressure shall be released gradually so as to reach atmospheric pressure in not less than 5 min, in order to avoid formation of porosity in the test pieces.                      Cable Testing Equipment
The test pieces shall then be removed from the bomb and left at ambient temperature, avoiding direct sunlight, for at least 16 h.
The tensile test shall then be carried out in accordance with Sub-clauses 9.1.6 and 9.1.7 of IEC Publication 811-1-1.

Standard: IEC60335-2-6 clause 22, IEC60335-2-9 clause 22,Clause 22.32 of IEC 60335-1 Household and similar electrical appliances – Safety – Part 1: General requirements, IEC 60811-1-1 sub clause 9.1 and IEC 60811-1-2 sub clause 8.3 and etc.

Application: It is used to process the aging test for the electric wire, the insulation layer and sheath of the rubber( plastic,artificial leather) as well as other high polymer materials under the action of required pressure and temperature in the medium of oxygen and compressed air.

Test sample: Wires, cables, rubber (plastic, leather) insulation layer and sheath, as well as other polymer materials.           Cable Testing Equipment

Feature: The device adopts inside and outside dual-chamber structure, the samples are suspended in an oxygen tube, filling with oxygen purity ≥ 97%, make the pressure up to 2.1 ± 0.07 MPa and maintain the temperature at 70 ° ± 1 ° C, then process aging test for 96 hours in this state.                                                   Cable Testing Equipment



Parameters:

Input Power 230V/50HZ
Maximum Operating Pressure 4MP
Secure Burst Pressure 2.7~3.3MP
Temperature-controlled range indoor temperature~200℃
Outer Chamber Dimensions 820mm×420mm×670mm
Inside Chamber Dimensions Diameter 123×Height 337mm
Inside Chamber Volume 4000cm³
Heating Power 2.4KW
Temperature Alarm 0~200℃ Adjustable
Temperature deviation ±0.5℃
Temperature Control Intelligent control
Temperature Display Thermometer display
Material Inside chamber is made of stainless steel and outer chamber is made of electrostatic spraying steel plate



IEC 60811 Cable Testing Equipment Oxygen Bomb / Air Bomb Aging Tester 200℃ 4MP 0

IEC 60811 Cable Testing Equipment Oxygen Bomb / Air Bomb Aging Tester 200℃ 4MP 1
