IEC60730-1 IEC Test Equipment Label Marking Abrasion Testing Sliding Weight 500g

IEC60730-1 IEC Test Equipment Label Marking Abrasion Testing Sliding Weight 500g

Brand Name:	HongCe
Model Number:	IN-2
MOQ:	1 set
Price:	Negotiatable
Payment Terms:	T/T
Supply Ability:	10 set /month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

calibration certificate (cost additional)

Product Name:

Label Marking Abrasion Test Machine

Warranty:

1 Year

Power:

220VAC 60Hz (or 110VAC 60Hz)

Standard:

IEC60730-1 Standard Figure 8 And Annex A

Application:

Marking

Lead Time:

20 Workdays

Brass Washer:

Φ60*2.5mm

Friction Wheel:

Φ65*7.5mm

Packaging Details:

plywood

Highlight:

IEC 60730-1 IEC Test Equipment

Label Marking IEC Test Equipment

Label Marking Abrasion Test Machine

Product Description

IEC60730-1 IEC Test Equipment Label Marking Abrasion Test Machine Sliding Weight 500g

Production introduction:

This testing apparatus is design and manufactured according to IEC60730-1 standard figure 8 and annex A requirements, used for testing the controller marking durability performance.

The apparatus comply with the dimensions requirements of IEC 60730-1 Figure 8. Test times can be set from 1 to 999999 (default as 12 times), test rate 48 rpm. It is a easy operated professional equipment. IEC Test Equipment

Main technical parameters:

Equipment	Markings durability tester
Test station	1 station
Test stroke	20mm
Test rate	48rpm
Test times	1~999999, default as 12times
Sliding weight	500g. Strip weight 250g, with weight 750g
Brass washer	Φ60*2.5mm
Friction wheel	Φ65*7.5mm
Power supply	220VAC 60Hz (or 110VAC 60Hz)
Standard	IEC 60730-1 Figure 8, Annex A
