Place of Origin: | China |
Brand Name: | HongCe |
Certification: | Third part calibration certificate(cost additional) |
Model Number: | HDX1314 |
Minimum Order Quantity: | 1 set |
---|---|
Price: | Negotiatable |
Packaging Details: | plywood |
Delivery Time: | 30 working days |
Payment Terms: | T/T |
Supply Ability: | 20 set per month |
Standard: | UL817 | Stations: | 6 |
---|---|---|---|
Load Current: | 0~40A , Arbitrary Adjustable | Load Voltage: | 4~12V |
Warranty: | 1 Year | Ambient Temperature: | 0~40℃ |
Ambient Humidity: | Less Than 85%Rh | Test Time: | 0.1~999.9S |
High Light: | 6 Stations Cable Testing Equipment,UL817 Cable Testing Equipment |
Cable Testing Equipment UL817 Abrupt Pull Test Apparatus Ambient temperature With 0~40°
Description of Cable Testing Equipment:
The power cord sudden tensile testing machine is a device used to test the tensile strength of power cords under extreme conditions. It simulates sudden pulls or cuts on the power cord, simulating real-world scenarios where the cord may be yanked or punctured. The machine measures the load required to break the cord, providing valuable insights into the durability and reliability of the cords.
This testing machine is essential for evaluating the quality of power cords used in various applications, including electrical appliances, equipment, and vehicles. It ensures that the cords can withstand sudden pulls or cuts without breaking, providing safe and reliable power connections.
Test sample of Cable Testing Equipment: Plug power line.
Feature of Cable Testing Equipment: Using automatic mode test, it will automatic shutdown when reach to the setting number if test times or setting time.
Technical parameters:
Power supply | AC 220V 50Hz |
Load current | 0~40A , Arbitrary adjustable |
Load voltage | 4~12V |
Working station | 6 stations |
Test times | 1~9999 times, can be preset |
Test time | 0.1~999.9S |
Load weight | 2.5 pound(lb) , 3 pound(lb) , 15 pound(lb) 6 pcs per each |
Ambient temperature | 0~40℃ |
Ambient humidity | less than 85%Rh |
Reference standard |
UL817 clause 96.4-96.5 Flexing test, clause 99.1-99.2 Abrupt Pull Test, clause 100.1-100.3 Jacket retention test |
Equipment detail drawing:
