| Place of Origin: | China |
| Brand Name: | HongCe |
| Certification: | Calibration certificate(cost additional) |
| Model Number: | HC9903B |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Plywood |
| Delivery Time: | 30 working days |
| Payment Terms: | T/T |
| Supply Ability: | 3 Sets per month |
| Standards Compliant: | UL486A-B | Number Of Trials: | 0-9999 Times, Can Be Preset |
|---|---|---|---|
| Counterweights: | 0.7-45.4kg Two Sets | Test Height: | 250~500mm |
| Test Rate: | 9±1 RPM | Driving Method: | Motor |
| High Light: | UL 486 Cable Testing Equipment,Cable Testing Equipment With 9rpm Rate |
||
Secureness Test Apparatus of UL 486 Cable Testing Equipment With 9rpm Rate
Product description of Cable Testing Equipment:
A conductor damage test device is a test device used to assess the damage of a conductor when subjected to mechanical stress. It is mainly used to inspect wires with threaded clamp type and non-threaded terminal fixed connection assemblies.
Product principle of Cable Testing Equipment:
The device works by rotating the device at a certain rate to apply mechanical stress to the conductor to simulate the stress that the wire might be subjected to in actual use. In this way, the extent of damage to the conductor can be tested to determine whether it can withstand the mechanical stresses that occur during normal use.
Feature of Cable Testing Equipment:
Our Secureness Test Apparatus has a dual station design that allows two different conductor to be tested simultaneously. This improves test efficiency, allowing more conductor to be tested at the same time.
In general, the wire damage test device is a device specifically used to test the damage degree of the wire, which can simulate the mechanical stress situation in actual use to help evaluate the quality and performance of the wire.
Parameters of Secureness Test Apparatus:
| Model | HC9903B |
| Test rate | 9±1 RPM |
| Diameter of gyration | 76mm |
| Test times | 0～9999 |
| Weights | 0.7, 0.9, 1.4, 2.3, 3.6, 4.5, 6.8, 11.4, 13.6, 18.2, 22.7, 27.2, 36.3, 45.4kg |
| Test height | 250~500mm. ( Height deviation of ±15mm) |
| Diameter of bushing | Total 18 pc, 6.4mm, 9.5mm, 12.7mm, 14.3 mm, 15.8mm, 19.1mm, 22.2mm, 25.4mm and 28.6mm, two of each |
| Standards | UL486A-B, UL498 |
Product detail picture of Cable Testing Equipment:
