Electrical Cable Damage Degree Test Apparatus for Conductor Integrity & Insulation Evaluation

Name: Electrical Cable Damage Degree Test Apparatus for Conductor Integrity & Insulation Evaluation
Brand: Guangzhou HongCe Equipment Co., Ltd.
SKU: HC9903B
Price: 5,000.00 USD
Availability: InStock

Brand Name:	HongCe
Model Number:	HC9903B
MOQ:	1 set
Price:	Negotiatable
Payment Terms:	T/T,L/C
Supply Ability:	10 set per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

TUV、ITS、CSA、BV、SGS 、CNAS(cost additional)

Company Specialization:

Manufacturing A Diverse Range Of Inspection Equipment

Standards Compliant:

UL486A-B, UL498

Counterweights:

0.7-45.4kg Two Sets

Sales Performance:

Remarkable Sales Performance Both At Home And Abroad

Weights:

0.7, 0.9, 1.4, 2.3, 3.6, 4.5, 6.8, 11.4, 13.6, 18.2, 22.7, 27.2, 36.3, 45.4kg

Test Rate:

9±1 RPM

Test Height:

250~500mm

Number Of Trials:

0-9999 Times, Can Be Preset

Packaging Details:

Plywood

Highlight:

cable damage test apparatus for conductors

electrical cable insulation evaluation equipment

conductor integrity testing device with warranty

Product Description

Electrical Cable Damage Degree Test Apparatus

Precision testing equipment for evaluating conductor integrity and insulation performance after mechanical stress. Manufactured by HongCe, this apparatus delivers repeatable, standard-compliant results for laboratories, certification bodies, and cable manufacturers focused on product safety and long-term reliability.

Key Features

Precision mechanical structure ensures stable and repeatable damage simulation
Accurate assessment of conductor damage degree and insulation integrity
Compatible with various cable diameters and constructions
Smooth operation with minimal mechanical loss
High-strength materials for extended service life
Easy specimen installation and removal process

Technical Specifications

Test Height	250~500mm
Test Rate	9±1 RPM
Diameter of Gyration	76mm
Number of Trials	0-9999 times, programmable preset
Counterweights	0.7, 0.9, 1.4, 2.3, 3.6, 4.5, 6.8, 11.4, 13.6, 18.2, 22.7, 27.2, 36.3, 45.4kg (Two Sets)
Driving Method	Motor
Standards Compliant	UL486A-B, UL498

International Standards Compliance

UL 486A-B - Wire Connectors – Mechanical Strength and Damage Evaluation
IEC 60227 / IEC 60245 - Polyvinyl chloride and rubber insulated cables
IEC 60811 - Common test methods for insulating and sheathing materials
ISO 6722 - Road vehicles – Single-core cables

Equipment Overview

Frequently Asked Questions

Is this apparatus suitable for different cable standards?

Yes. The apparatus is designed to meet multiple international standards and can be customized for specific test clauses.

Can the equipment test automotive cables?

Yes. It is suitable for automotive electrical cables and wiring harness conductors.

Is customization available?

Absolutely. HongCe supports customized fixtures, stroke ranges, and test parameters.

Is calibration required?

Routine inspection is recommended to ensure long-term accuracy.

Do you provide technical training?

Yes. Operation guidance and technical support are provided.

Manufacturer: Guangzhou HongCe Equipment Co., Ltd.
Location: Guangdong, China
After-sales Service: Global support with fast and efficient service teams
