Plug Socket Tester
Created with Pixso.

3-position Switch Plug And Socket Durability Tester IEC60884-1 AC230V 50Hz

3-position Switch Plug And Socket Durability Tester IEC60884-1 AC230V 50Hz

Brand Name: HongCe
Model Number: HC9914C1
MOQ: 1 Set
Price: Negotiable
Payment Terms: L/C, T/T
Supply Ability: 10 set per month
Detail Information
Place of Origin:
China
Certification:
Calibration certificate(cost additional)
Power:
AC230V, 50Hz
Work Station:
3 Stations
Operation Interface:
7-inch Touch Screen
Drive Mode:
Cylinder
Control System:
PLC Control
Test Times:
0~999999 Times, Can Be Preset
Conduction Time:
0~99.9s, Can Be Preset
Test Stroke:
100mm
Test Rate:
15 Times/min,7.5 Times/min,30 Times/min
Warrante Period:
1 Year
Packaging Details:
Plywood
Highlight:

3 Position Plug Socket Tester

,

AC230V Plug Socket Tester

,

IEC60884-1 Plug Socket Tester

Product Description

3-position switch plug and socket durability tester IEC60884-1 AC230V, 50Hz



Product Introduction with Plug Socket Tester:

The equipment is meticulously engineered in strict compliance with standards like IEC60884 - 1 and IEC61058 - 1, tailored specifically for switches, plugs, and sockets in household and analogous electrical appliances. It conducts an exhaustive evaluation of these components’ mechanical and electrical durability by simulating prolonged, repetitive rotation, insertion, and extraction maneuvers. The machine meticulously scrutinizes contact points to guarantee no adhesion, abnormal closure, or disconnection occurs. Meanwhile, it continuously monitors wear - and - tear to proactively preclude potential hazards. This makes it the optimal choice for electrical endurance testing, setting a benchmark for reliability and precision in assessing electrical component longevity.



Application Range with Plug Socket Tester:

The test equipment is proficient in conducting endurance testing for button switches, plugs, and sockets. When integrated with an external load bank (resistive, inductive, and capacitive), it can execute loading tests, supported by its dedicated control system. It should be emphasized that users are required to prepare the external load bank independently.



Product Features with Plug Socket Tester:

This testing machine is constructed with a sturdy aluminum - alloy frame and a stainless - steel sealing plate, and is driven by a high - precision cylinder. It is equipped with a 7 - inch high - definition color touch screen and an advanced PLC control system, featuring a user - friendly operation interface and powerful digital display functions. The test times, conduction current time, and test speed can be easily preset. It has a real - time current display function, which can accurately display the conduction current of the sample. The entire testing machine is equipped with three independent workstations. When there is continuous switching due to adhesion or malfunctions, it will automatically alert and record the corresponding test count. Moreover, when the test times reach the preset value, an alarm will be triggered, and the equipment will automatically shut down when an alarm is activated.



Product Parameters with Plug Socket Tester:

Power AC230V, 50Hz
Work station 3 stations
Operation interface 7-inch touch screen
Drive mode Cylinder
Control system PLC control
Test times 0~999999 times, can be preset
Conduction time 0~99.9s, can be preset
Test stroke 100mm
Test rate 15 times/min,7.5 times/min,30 times/min



Product Image with Plug Socket Tester:

3-position Switch Plug And Socket Durability Tester IEC60884-1 AC230V 50Hz 0



3-position Switch Plug And Socket Durability Tester IEC60884-1 AC230V 50Hz 1



3-position Switch Plug And Socket Durability Tester IEC60884-1 AC230V 50Hz 2
