Compression Test Device Multi-function Socket Tester Plug Socket Tester Complies With IEC60884-1 Standard

Name: Compression Test Device Multi-function Socket Tester Plug Socket Tester Complies With IEC60884-1 Standard
Brand: Guangzhou HongCe Equipment Co., Ltd.
SKU: HC9902
Price: 5,000.00 USD
Availability: InStock

Brand Name:	HongCe
Model Number:	HC9902
MOQ:	1 Set
Price:	Negotiable
Payment Terms:	L/C,T/T
Supply Ability:	30 set per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Calibration certificate(cost additional)

Name:

Compression Testing Machine

Warranty:

1 Year

Material:

Stainless Steel

Test Station:

1 Station

Test Weight:

300N

Operating Method:

By Manual

Test Sample:

Plugs

Application:

Compression Test

Packaging Details:

Plywood

Highlight:

Compression test device Plug Socket Tester

Multi-function Plug Socket Tester

IEC60884-1 Plug Socket Tester

Product Description

Compression test device Multi-function socket tester Plug Socket Tester Complies with IEC60884-1 standard

Product Introduction:
HC9902 is a groundbreaking multifunctional testing equipment that integrates material compression performance testing and socket electrical safety analysis. It is designed for industrial manufacturing, quality inspection laboratories and construction engineering fields.

Key Features & Advantages:

Dual-Standard Compliance:
Meets IEC60884-1 Figure 8 and GB2099.1-2008 Clauses 10.1/24.5 requirements for plug compression testing.

Precision Force Application:
Adjustable weights deliver 150N or 300N vertical force (23±2°C ambient) to test points A/B per standard specifications.

Industrial-Grade Construction:
Stainless steel frame ensures long-term stability, resisting wear from repeated 1-minute load cycles.

Manual Control Reliability:
Operator-driven design eliminates electronic drift risks, providing consistent test reproducibility.

Global Certification Ready:
Includes optional calibration certificates for international market approvals (CE, UL, etc.).

Parameters With Plug Socket Tester:

Name	Compression Testing Machine
Warranty	1 Year
Material	Stainless Steel
Test Station	1 Station
Test Weight	300N
Operating Method	By manual
Test Sample	Plugs
Application	Compression Test

Applications:

Quality Assurance: Verify plug housing integrity pre-shipment.

R&D Validation: Test new plug designs against deformation thresholds.

Safety Certification: Prepare samples for IEC/GB compliance audits.

Production Line QC: Monitor manufacturing consistency for sockets/plugs.

Product Details With Plug Socket Tester:

Customization & Support:

Tailored Solutions:
Leverage HongCe's in-house engineering team to modify force ranges (up to 500N) or adapt fixtures for proprietary plug designs.

Global After-Sales Network:

24/7 remote troubleshooting via video call.

On-site technician dispatch in 48hrs (Asia/Europe/N. America).

Lifetime software/firmware updates for protocol changes.

Tags:

Plug Compression Tester 300N Manual Pressure Tester IEC Certification Plug Socket Tester Mechanical Strength Testing Anti-Electric Shock Protection Multi Standard Compatibility
