| Pendulum Length: | 1000mm | Striking Element: | 200g |
|---|---|---|---|
| Mounting Bracket: | 10±1 Kg | Pendulum Diameter: | 9mm |
| Highlight: | Flexible Pendulum impact testing machine,Adjustable Speed Pendulum impact testing machine,Adjustable Height Pendulum impact testing machine |
||
Pendulum impact testing machine with adjustable height and impact speed for flexible testing
Standard:
IEC60068-2-75 Environmental testing - Part 2-75: Tests - Test Eh: Hammer tests
IEC 60884-1 Plugs and socket - outlets for household and similar purposes - Part 1: General requirements
ISO 179 - 1:2010 Plastics - Determination of Charpy impact properties - Part 1: Non - instrumented impact test
Product introduction:
The pendulum impact test device is an important device for evaluating the impact resistance of materials. It releases the pendulum from a certain height, impacts the sample fixed on the fixture at a predetermined speed, and then measures the energy loss of the pendulum during the impact process to determine the impact toughness or impact resistance of the material.
The device is mainly composed of a pendulum, a rack, a sample fixture, an energy measurement system and a control system. The pendulum is the core component, and its mass and the length of the swing arm determine the size of the impact energy; the rack provides stable support for the entire device; the sample fixture ensures that the sample is accurately positioned and firmly fixed during the impact process; the energy measurement system accurately records the energy difference before and after the pendulum impact; the control system facilitates users to set test parameters and operate the test process.
Pendulum impact tester parts
Impact testing machine application scope:
Applicable to all kinds of material production enterprises, including metal smelting, plastic processing, composite material manufacturing and other industries, for product quality control and new material research and development. At the same time, it is also suitable for material performance research and teaching experiments in scientific research institutions, colleges and universities.
Impact testing machine application scenarios:
Material research and development: In the process of new material development, the impact resistance of materials is tested by pendulum impact test device in order to optimize material formula and manufacturing process, and improve the toughness and reliability of materials.
Quality control: In industrial production, regular pendulum impact tests are carried out on raw materials and finished products to ensure that the products meet relevant quality standards and performance requirements. For example, in the automobile manufacturing industry, impact tests are carried out on automobile parts (such as bumpers, engine parts, etc.) to ensure the safety of automobiles in collisions; in the production of plastic pipes, the impact resistance of pipes is tested to ensure that they can withstand certain external force impacts without breaking during installation and use.
Product certification: Many products need to pass relevant certifications before they are put on the market, such as building materials, electronic and electrical products, etc. The pendulum impact test device can be used to obtain product impact resistance data to meet certification requirements.
Teaching and scientific research: As an important experimental equipment, it helps students and researchers to deeply understand the mechanical properties of materials and carry out related scientific research projects in the teaching and scientific research of materials science, mechanical engineering and other related majors in colleges and universities and research institutes.
Pendulum impact testing machine components
Parameters:
1. Pendulum: Length: 1000mm; external diameter: 9mm; steel pipe wall thickness: 0.5mm; material: steel; weight: 100±1g
2. Mounting bracket: weight: 10±1 kg; it is well-set and the Horizontal direction and the vertical direction can be adjusted. The whole bracket can be rotated 90°through the rotation axis.
3. Striking element: 150g, equivalent mass 200g. (200g striking element for option).
4. Height of fall table
| Energy/J | 0.14 | 0.2 | (0.3) | 0.35 | (0.4) | 0.5 | 0.7 | 1 | 2 | 5 | 10 | 20 | 50 | ||
| Equivalent mass /kg | 0.25 | (0.2) | 0.25 | (0.2) | 0.25 | (0.2) | (0.2) | 0.25 | 0.25 | 0 .25 | 0.5 | 1.7 | 5 | 5 | 10 |
| Drop height ±1%mm | 56 | (100) | 80 | (150) | 140 | (200) | (250) | 200 | 280 | 400 | 400 | 300 | 200 | 400 | 500 |
|
Notes:
|
|||||||||||||||
Q1: How to choose the right pendulum energy?
The pendulum energy should be selected based on the expected impact resistance of the material to be tested and the required test accuracy. Generally, the energy of the pendulum should be at least twice the energy required for the expected material to break.
Q2: How to interpret the test results?
The test results are usually expressed in impact absorption energy (Joules), which reflects the energy absorption capacity of the material under impact. Higher absorption energy means better impact resistance.
Q3: What is the calibration and maintenance cycle of the equipment?
It is recommended to perform professional calibration at least once a year and routine maintenance based on the frequency of use to ensure the accuracy of the test results.
