IEC 60884 Testing Equipment For Marking Durability Test With 5-60 Times / Min Test Speed

Brand Name:	Hongce
Model Number:	HC9950
MOQ:	1 set
Price:	Negotiation
Payment Terms:	T/T
Supply Ability:	10 Sets per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Calibration certificate(cost additional)

Test Stroke:

70mm

Specification:

Two Axes

Speed:

5-60times/min, Adjustable

Voltage:

220V, 50Hz

Test Piston:

According Figure 5

Compression Force:

5±1N

Packaging Details:

Plywood

Highlight:

IEC 60884 Testing Equipment

60 Times / Min Durability Testing Equipment

Product Description

IEC 60884 Testing Equipment for Marking Durability Test With 5-60times/min Test Speed

Standard of IEC Test Equipment:

IEC 60884-1:2022 Plugs and socket-outlets for household and similar purposes - Part 1: General requirements clause 8.8 and figure 5.

Application of Marking Durability Test Apparatus:

This test may also be referred to as Durability of Identification, Durability of Marking, Rubbing shall commence immediately after soaking the piece of cotton, applying a compression force of (5± 1)N at a rate of about one cycle per second (a cycle comprising a forward and backward movement along the length of the marking). For markings longer than 20 mm, rubbing can be limited to a part of the marking, over a path of at least 20 mm length.

Product function of IEC Test Equipment:

The friction test product can simulate the friction situation under different environment and use conditions by adjusting the pressure, speed, temperature and other parameters of the friction wheel, as well as changing the material and shape of the friction wheel. This helps to evaluate the durability of materials more comprehensively, and provides an important reference for product design, production and application.

Technical specification of IEC Test Equipment:

No.	project	Arguments
1	Specification	Two axes (can be used as both rubber and alcohol friction, pencil hardness test can also be added)
2	Test stroke	70mm
3	Speed	5-60times/min, adjustable
4	Counter	0-9999 adjustable
5	Weight	50, 100, 200, 300, 500g Two each, Can be customized according to user requirements
6	Voltage	220V, 50Hz
7	Machine size	500300550mm
8	Accessories	Alcohol rubbing fixture 2 pcs, rubber rubbing fixture 2 pcs, pencil friction fixture 2 pcs, cotton cloth, eraser 2 pcs

Product details of IEC Test Equipment:
