IEC60068-2-75 Impact Testing Machine Nylon Base 1000*1000mm Thickness 8mm

IEC60068-2-75 Impact Testing Machine Nylon Base 1000*1000mm Thickness 8mm

IEC60068-2-75 Impact Testing Machine Nylon Base 1000*1000mm Thickness 8mm
IEC60068-2-75 Impact Testing Machine Nylon Base 1000*1000mm Thickness 8mm
IEC60068-2-75 Impact Testing Machine Nylon Base 1000*1000mm Thickness 8mm
Product Details:
Place of Origin: China
Brand Name: HongCe
Certification: calibration certificate (cost additional)
Model Number: SH-9A
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiatable
Packaging Details: plywood
Delivery Time: 30 days
Payment Terms: T/T
Supply Ability: 10 set /month
Contact Now
Detailed Product Description
Product Name: Vertical Hammer Test Apparatus Usage: Hammer Test
Warranty: 1 Year Standard: IEC60068-2-75
Drop Height: 0-1000mm Nylon Base Size: 1000mm*1000mm
Nylon Base Thickness: 8mm Nylon Base Hardness: HRR85-100
High Light:

IEC60068-2-75 Impact Testing Machine

,

Nylon Base Impact Testing Machine

,

Thickness 8mm Impact Testing Machine

IEC60068-2-75 Impact Testing Machine Nylon Base 1000*1000mm Thickness 8mm​



Introduction:

This device conforms to the standard requirement of the IEC60068-2-75 Test Ehc. It is for testing enclosure mechanical strength of household and similar electrical appliances, lamps. The device is released by the electromagnet, which can ensure the instantaneous release and the vertical drop. The lifting device is combined by screw guide rail, which can make the lower end of the conduit smooth contact with the surface of the specimen, the fixed drop height is the length of the guide rail, just contact no need to adjust, easy to use. Standard equipped with 2, 5, 10, 20, 50 J hammer and conduit, it is suitable for the enclosure mechanical strength test of most products.

Notice:

1. The power should be cut off after the test is completed, to prevent overheating of the electromagnet.

2. The sample should be installed before the hammer is drop, impact is not allowed without installing the sample, avoid damaging the hammer.

3. Please pay attention to being dampproof and dustproof and maintenance.



Standard: IEC 60068-2-75 Test Ehc: vertical hammer, UL498 clause SD7.2

Application: This device is intended to test the mechanical strength test of the shell of the electric appliance for house hold and similar purpose, as well as test drop impact resistance of the lamp.             Impact Testing Machine

Test sample: Electric appliance, plug and socket, luminaries for house hold and similar purpose

Feature: Comply with the requirement of standard IEC60068-2-75. Cantilever type rack, release the impact element by electromagnet, impact height determined by guide tube.              Impact Testing Machine

Parameters:

Model SH-9 SH-9A SH-9B
Release mode Electromagnet release Electromagnet release Electromagnet release
Drop floor

Nylon base 600mm*600mm; thickness 8mm;

hardness HRR85-100.

Nylon base 1000mm*1000mm; thickness 8mm;

hardness HRR85-100.

Hard wood board

114x114x42 mm

Drop height 300mm 0-1000mm adjustable 457 mm
Impact hammer 5J 2J, 5J, 10J, 20J, 50J

Φ50.8mm Cylinder head,

weight 4.5kg

Standards IEC 60068-2-75 IEC 60068-2-75 UL498
