| Place of Origin: | China |
| Brand Name: | HongCe |
| Certification: | Third party calibration certificate(cost additional) |
| Model Number: | HC9910C |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | plywood |
| Delivery Time: | 30 days |
| Payment Terms: | T/T |
| Supply Ability: | 10 set /month |
| Standart: | IEC60884-1 | Working Station: | 6 |
|---|---|---|---|
| Testing Current: | 0-125A | Testing Voltage: | ＜12V |
| Temperature Measuring Meter: | 0-150℃ Digital Display | Test Object: | Connector |
| Control Method: | PLC Control | Operate Method: | Touch Screen Operation |
| High Light: | IEC60884-1 Plug Socket Tester,125A Plug Socket Tester,PLC Control Plug Socket Tester |
||
IEC60884-1 Plug Socket Tester Temperature Rising Tester 0-125A Testing Current
Standard: IEC 60884-1 2013 clause 19, IEC 60998.1, VDE0620
Application: This device is use for test the temperature rise under normal operation of electrical appliances.
Test sample: Household plugs and sockets Plug Socket Tester
Feature: External type, thermocouple wire directly connected to the sample.
PLC control and touch screen operation, record the temperature of 6 points and display it on the touch screen. If the temperature reaches the set value, it will stop automatically. Historical data can be stored for 15 days and can be read through USB. Plug Socket Tester
Parameters:
| Item | HC9910C |
| Working station | 6 |
| Testing current | 0-125A |
| Testing voltage | ＜12V |
| Timer | 0-9999s is adjustable, digital display |
| Temperature measuring meter | 0-150℃ digital display |
| Power supply | 220V,50HZ |
| standard | IEC 60998.1 |
| Test object | connector |
Picture for reference:
