Impact Testing Machine
Created with Pixso.

YDT757 Hammer Test Device Impact Height 300mm Hammer Blade Width 20mm

YDT757 Hammer Test Device Impact Height 300mm Hammer Blade Width 20mm

YDT757 Hammer Test Device Impact Height 300mm Hammer Blade Width 20mm

Brand Name: HongCe
Model Number: HTD-1
MOQ: 1 set
Price: Negotiatable
Payment Terms: T/T
Supply Ability: 25 set per month
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
Calibration Certificate(cost additional)
The Mass Of Hammer:
210g±1g
Impact Height:
300mm
Thickness Of The Base:
15mm
Hammer Blade Width:
20mm
Dimension Of The Base:
250mm*250mm
Standard:
YDT757
Warranty:
1 Year
Product Name:
Hammer Test Device
Packaging Details:
Plywood
Highlight:

Impact Height 300mm Hammer Test Device

,

Blade Width 20mm Hammer Test Device

Product Description

YDT757 Hammer Test Device, Impact Height 300mm, Hammer Blade Width 20mm



  • The device shall be installed on a stable wooden test bench, and the test surface shall be kept at the same height as the hammer base.
  • The test piece shall be placed horizontally, the hammer head shall face the center of the bench, the hammer handle shall fall freely after being perpendicular to the plane of the base, strike 5 points in parallel at an interval of 4mm, and check the surface state of the zinc layer. The striking point shall be 10mm away from the end, and the striking place shall not be struck twice at the same time.

Standard: YDT757
Application: This device is suitable for the adhesive force test of hot dip galvanizing coatings.
Test sample: Electroplating, tower similar products
Feature: The free fall hammer hit the sample to test whether the galvanized layer meet the standard requirements. This product is suitable for product quality inspection and control.
Parameters:
1. The mass of hammer: 210g±1g
2. The vertical height from the hammer centre line to the base surface: 300mm±1mm
3. The material of the hammer handle: oak
4. Base: 250*250*15mm. provide level bubble, adjustable leve





Technical parameters:



The mass of hammer 210g±1g
The vertical height from the hammer centre line to the base surface 300mm±1mm
The material of the hammer handle  oak



YDT757 Hammer Test Device Impact Height 300mm Hammer Blade Width 20mm 0
