IEC 60884-1 Fig 8 Plug Socket Tester Compression Testing Machine With 2PCS 150N Weights

IEC 60884-1 Fig 8 Plug Socket Tester Compression Testing Machine With 2PCS 150N Weights

  • IEC 60884-1 Fig 8 Plug Socket Tester Compression Testing Machine With 2PCS 150N Weights
  • IEC 60884-1 Fig 8 Plug Socket Tester Compression Testing Machine With 2PCS 150N Weights
  • IEC 60884-1 Fig 8 Plug Socket Tester Compression Testing Machine With 2PCS 150N Weights
IEC 60884-1 Fig 8 Plug Socket Tester Compression Testing Machine With 2PCS 150N Weights
Product Details:
Place of Origin: China
Brand Name: HongCe
Certification: Calibration certificate(cost additional)
Model Number: HC9902
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Plywood
Delivery Time: 30 days
Payment Terms: T/T
Supply Ability: 30 set per month
Contact Now
Detailed Product Description
Name: Compression Testing Machine Warranty: 1 Year
Material: Stainless Steel Test Station: 1 Station
Test Weight: 300N Operating Method: By Manual
Test Sample: Plugs Application: Compression Test
High Light:

150N Plug Socket Tester

,

Fig 8 Plug Socket Tester

,

1 Station Compression Testing Machine

IEC 60884-1 Fig8 Plug Socket Tester Compression Testing Machine With 2PCS 150N Weights



IEC60884-1 Clause 24.5

The specimens are subjected to a compression test as shown in figure 8, the temperature of the pressure plate, of the base and of the specimens being (23 ± 2) °C and the force applied being 300 N.
The specimens are first placed in position a), as shown in figure 8, and the force is applied for 1 min. They are then placed in position b), as shown in figure 8, and again subjected to the force for 1 min.                             Plug Socket Tester
The specimens are removed from the test apparatus and after 15 min they shall show no damage within the meaning of this standard.

Standard: IEC 60884-1 2013 clause 10.1, 24.5 and figure 8

Application: This device is use for testing the compression resistance performance of plug, check whether the mechanical strength of plug comply with standard requirements.                  Plug Socket Tester

Test sample: Plugs

Feature: This device applying compression force 300N by weights. The temperature of the pressure plate, of the base and of the specimens being 23±2℃, compress the plug in two position show as figure 8a) and 8b), each position for 1min.                      Plug Socket Tester

Parameters:



Name Parameter
Weights                      Plug Socket Tester 300N (pile up with 2 150N weights)
Station 1 station
Operation manual
Test time 1min



IEC 60884-1 Fig 8 Plug Socket Tester Compression Testing Machine With 2PCS 150N Weights 0

IEC 60884-1 Fig 8 Plug Socket Tester Compression Testing Machine With 2PCS 150N Weights 1
