| Place of Origin: | China |
| Brand Name: | HongCe |
| Certification: | Calibration certificate(cost additional) |
| Model Number: | VF-1 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plywood |
| Delivery Time: | 30 days |
| Payment Terms: | T/T |
| Supply Ability: | 10 set per month |
| Product Name: | Electric Wire Flame Resistance Test Apparatus | Warranty: | 1 Year |
|---|---|---|---|
| Power: | AC 220V/50HZ | Standard: | IEC60332-1-1, IEC60332-1-2, IEC60332-1-3 |
| Burning Angle: | Tilt 45°±2° | Test Flame Calibration: | K-Thermocouple,temperature Resistance 1100° |
| Fixed Horizontal Support Of The Sample: | 2, Distance:550mm | Burning Time: | 9999X0.1S |
| High Light: | IEC 60332-1 Flammability Testing Equipment,Single Insulated Wire Flammability Testing Equipment,Tilt 45° Flammability Testing Equipment |
||
IEC60332-1 Flammability Testing Equipment For Single Insulated Wire or Cable Burner Tilt 45°
Purpose:
When the wire and cable products are short circuited or exposed to fire, the insulation or sheath may burn. In many occasions (coal mines, ships, subways, shopping malls and other public places) where strict fire prevention is required, the flame should not spread in case of combustion, but extinguish itself in a certain period of time and a certain length, which is called non flame retardancy. In some cases, if the product does not have this function, it will cause extremely serious personal injury and property losses.
Therefore, in the production process, PVC, chloroprene rubber and butylamine PVC composites are widely used as insulation and sheath materials for products with non flame retardancy. When these materials are burned, chlorine will be released to play a flame retardant role. Sometimes in order to enhance the effect of flame retardant, some flame retardant is added.
Flammability Testing Equipment
Standard: IEC60332-1-1:2004,IEC60332-1-2:2004,IEC60332-1-3:2004, IEC 60950-1,BS EN 60950-1,BS 7002, UL746A,IEC60947.1, IEC730.1. Flammability Testing Equipment
Application:Suitable for vertical burning test of single cable or optical cable products, determine the combustion characteristics of insulating materials.
Test sample:Single cable or optical cable products.
Feature:Using integral intake automatic ignition system, combustion time delay only 0.1s to ensure that the full combustion of the gas.
Parameters:
| Working voltage | 220V/50Hz |
| Control operation mode | Electrical control, button operation |
| Blast burner | Burner opening:Φ7±0.05mm,made of brass |
| Gas flow and gas category | Mixture gas:650±30mL/min propane；10±0.5L/min air,Dual flow meter adjustment |
| Burning time | 9999X0.1S |
| Burning angle | Tilt 45°±2°,Adjustable |
|
Test flame calibration
Flammability Testing Equipment |
Temperature measuring copper head:500W:Ф9mm±0.01mm,weight before drilling:10 ± 0 .05g |
| Thermocouple:The American original Omega φ0.5 armour nickel-chromium/nickel aluminum wire K-Thermocouple,temperature resistance 1100° | |
| Distance between the bunsen burner port to temperature measuring copper block:95 mm | |
| Flame height:Inner flame:55±5mm,Outer flame:180±10mm | |
| Temperature rise time from 100±5°C to 700°±3°C 45±5s | |
| Combustion chamber | WDH=300×450×1200±25mm |
| Gas | >95% propane or coal gas |
| Test sample | Length:600±25mm, distance from the bottom:50mm |
| Fixed horizontal support of the sample | 2, distance:550mm |
| Dimension | WDH=700×450×1350mm, weight about 90kg |
