IEC60068-2-75 Impact Testing Machine Striking Element 5J 10J 20J

Brand Name:	HongCe
Model Number:	SH-10
MOQ:	1 set
Price:	Negotiatable
Payment Terms:	T/T
Supply Ability:	50 set/ month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Calibration certificate(cost additional)

Name:

Striking Element

Energy:

2J/5J/10J/20J/50J

Function:

Impact Test

Standard:

IEC60068-2-75 Annex A

Equivalent Mass:

0.5kg/1.7kg/5kg/5kg/10kg

Diameter(mm):

35/60/80/100/125

Material:

SUS304

The Height Of Dropping ±1%/mm:

400/300/200/400/500

Packaging Details:

Carton Box

Highlight:

20J Impact Testing Machine

IEC 60068-2-75 Impact Testing Machine

10J Striking Element

Product Description

IEC60068-2-75 Impact Testing Machine Striking Element 5J 10J 20J

Standard description (IEC60068-2-75):

Figure A.1 shows the striking element applicable to energy values of equal or less than 1J. In this case, the impact face should be made of polyamide with a hardness as specified in Table 1 . Impact Testing Machine
Figures A.2, A.3 and A.4 show the striking elements applicable to energy values of 2J, 5J and 10J, respectively. In these cases the impact face should be made of steel with properties, including hardness, as specified in Table 1 .
Figures A.5 and A.6 show the striking elements applicable to energy values of 20 J and 50J, respectively. In these cases, the impact face should be made of steel with properties, including hardness, as specified in Table 1 . In these cases, to comply with the other parameters of Table 1 , it is necessary to hollow out the end opposite to the striking face.
Every edge shall be smoothed. Impact Testing Machine
The tolerances are as per class m of ISO 2768-1 , unless otherwise stated.

IEC60068-2-75 Impact Testing Machine Striking Element 5J 10J 20J 0

IEC60068-2-75 Impact Testing Machine Striking Element 5J 10J 20J 1

IEC60068-2-75 Impact Testing Machine Striking Element 5J 10J 20J 2

IEC60068-2-75 Impact Testing Machine Striking Element 5J 10J 20J 3

IEC60068-2-75 Impact Testing Machine Striking Element 5J 10J 20J 4

IEC60068-2-75 Impact Testing Machine Striking Element 5J 10J 20J 5

IEC60068-2-75 Impact Testing Machine Striking Element 5J 10J 20J 6

Standard: IEC60068-2-75 Annex A

Application: This device is suitable for mechanical impact strength test to electric cabinets and other sheet metal, shell of Non metal electric energy metering cabinet, substation cable switchboard and cable junction box with vertical impact tester or pendulum impact device.

Test sample: Electrical appliance for household and similar purpose, luminaries

Feature: In according with the standard requirement Impact Testing Machine

Parameters:

Model(Energy)	2J	5J	10J	20J	50J
equivalent mass(kg)	0.5	1.7	5	5	10
Dripping height(±1% mm)	400	300	200	400	500
Diameter(mm)	35	60	80	100	125

IEC60068-2-75 Impact Testing Machine Striking Element 5J 10J 20J 7
