Storage Water Heater Appliance Performance Test Lab With 6 Stations

Brand Name:	HongCe
Model Number:	HCWHEF01
MOQ:	1 set
Price:	Negotiatable
Payment Terms:	T/T
Supply Ability:	1 set /month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

calibration certificate (cost additional)

Product Name:

Storage Water Heater Appliance Performance Test Lab

Standard:

IEC 60379, GB 21519

Relative Air-humidity:

Not Exceeding 85%

Ambient Temperature:

θamb Of 20 ± 2 °C

Water Temperature Fluctuation:

θC Of 15 ± 2 °C

Test Room Size:

6000*4000*2600mm

Test Station:

6 Stations

Water Temperature Range:

10-65 °C

Packaging Details:

plywood

Highlight:

6 Stations Appliance Performance Test Lab

GB 21519 Appliance Performance Test Lab

Water Heater Appliance Performance Test Lab

Product Description

Storage Water Heater Appliance Performance Test Lab With 6 Stations

Standard:

IEC 60379 Methods for measuring the performance of electric storage water-heaters for household purposes.

GB 21519 Minimum allowable values of energy efficiency and energy efficiency grades for electrical storage water heaters.

Equipment system composition:

Test room: The test room has strict temperature and humidity requirements and is realized by computer room air conditioner.

Sample mounting bracket: 2pcs, installed in the test room, arranged on both sides, each test bracket has 3 test stations.

Water supply room: include 2 water storage tanks, and constant temperature and constant pressure water supply line pipe.

Control cabinet: It is the data collection, data processing and control center of the system. Appliance Performance Test Lab

Mounting of the water-heater:

Wall-mounted water-heaters are mounted on a panel situated at least 150 mm from any structural wall.

They are positioned so that there is a clear space of at least 250 mm above and below the heater and at least 700 mm at the sides and front.

Floor-mounted water-heaters are placed on the floor or on any stand supplied with them. A false floor may be used to facilitate measurements.

Water-heaters for building-in are built in according to the manufacturer's instructions.

Parameter:

Test room size	600040002600mm
Test room temperature	20 ± 2 °C
Test room humidity	<85%
Sample mounting bracket	2PCS
Test station	6 stations
Water tank	2PCS
Water temperature range	10-65 °C
Water supply line pipe	2 channels
Water pressure range	0.1-0.5Mpa. Appliance Performance Test Lab
