IEC 60884-1 300N Plug Socket Tester Compression Test Device HC9902

IEC 60884-1 300N Plug Socket Tester Compression Test Device HC9902

  • IEC 60884-1 300N Plug Socket Tester Compression Test Device HC9902
  • IEC 60884-1 300N Plug Socket Tester Compression Test Device HC9902
  • IEC 60884-1 300N Plug Socket Tester Compression Test Device HC9902
IEC 60884-1 300N Plug Socket Tester Compression Test Device HC9902
Product Details:
Place of Origin: China
Brand Name: HongCe
Certification: Calibration certificate(cost additional)
Model Number: HC9902
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Plywood
Delivery Time: 30 days
Payment Terms: L/C, T/T
Supply Ability: 30 set per month
Contact Now
Detailed Product Description
Name: Compression Testing Machine Warranty: 1 Year
Material: Stainless Steel Test Station: 1 Station
Test Weight: 300N Operating Method: By Manual
Test Sample: Plugs Application: Compression Test

IEC 60884-1 300N Plug Socket Tester Compression Test Device HC9902



Introduction of the Plug Socket Tester



Comply with standards: GB2099-1-2008 Clauses 10.1 and 24.5 and Figure 8, IEC60884-1 Figure 8

Purpose: Suitable for pressure testing of plugs to check whether the mechanical strength of the plug meets standard requirements. Sample range: plug

Structure and function: Use weights to apply force, 150N and 300N are superimposed forces. The temperature should be kept at 23±2°C during the test, and a pressure of 300N should be applied to the sample at two positions a and b in standard Figure 8 for 1 minute each.



Parameters With Plug Socket Tester:



Name Compression Testing Machine
Warranty 1 Year
Material Stainless Steel
Test Station 1 Station
Test Weight 300N
Operating Method By manual
Test Sample Plugs
Application Compression Test



IEC 60884-1 300N Plug Socket Tester Compression Test Device HC9902 0



Product Details With Plug Socket Tester:



IEC 60884-1 300N Plug Socket Tester Compression Test Device HC9902 1

IEC 60884-1 300N Plug Socket Tester Compression Test Device HC9902 2IEC 60884-1 300N Plug Socket Tester Compression Test Device HC9902 3

Our advantage service:

We have our own developing and designing team, which ensure our own technological and innovative products for customers.
For any customers who have new idea about some products, just let us know, we can according to your idea provide a unique design of the products.



Technical support:

All our workers are experienced and skilled.


After sale service:
Our working team and sales teams can guarantee a fast and high efficiency after-sale service for our product sold to everywhere of the global.



About Us:



Guangzhou Hongce Equipment Co., Ltd is a leading company in inspection equipment industry, established in 2003 and located in Guangdong, China. Our company introduced advanced equipment, combined with the most advanced technology production processes, strict quality control system to control the entire process of production. The company combined with a number of high-tech management personnel and advanced equipment, and together with the modern management, computer design and control, our products has reached the international advanced level. The company set R&D design, production, sales as one, specializing in producing electric wire inspection equipment of plug and socket, mechanical robustness testing equipment of electronics, inspection equipment of electronics’ on-fire danger, testing indicator of anti-electric shock and solid objects' entry, general inspection equipment, and other non-standard testing equipment. Our products enhance good selling at home and abroad, and have established supply relationships with a number of well-known companies.
