| Place of Origin: | China |
| Brand Name: | HongCe |
| Certification: | Third part calibration certificate(cost additional) |
| Model Number: | SH-0.5J |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiatable |
| Packaging Details: | Carton box |
| Delivery Time: | 3 days |
| Payment Terms: | T/T |
| Supply Ability: | 20 set per month |
| Product Name: | Spring Hammer Test Apparatus | Impact Energy: | 0.5J |
|---|---|---|---|
| Impact Element Mass: | 250g±5g | Overall Mass: | 1250g±10g |
| Material: | Stainless Steel | Application: | Appliance Mechanical Strength Test |
| Standard: | IEC 60335-1, IEC 60068-2-75 | Name: | Spring Impact Hammer |
| High Light: | IEC 60335 Home Appliance Testing Equipment,0.5J Home Appliance Testing Equipment |
||
IEC 60335 Home Appliance Testing Equipment Spring Hammer Test With 0.5J Impact Energy
Standard of Home Appliance Testing Equipment:
IEC 60335-1: 2020 Household and similar electrical appliances – Safety – Part 1: General requirements clause 21.1;
IEC 60068-2-75: 2014 Environmental testing – Part 2-75: Tests – Test Eh: Hammer tests clause 6 and Annex E;
Application of Home Appliance Testing Equipment:
Appliances shall have adequate mechanical strength and be constructed to withstand such rough handling that may be expected in normal use.
Compliance is checked by applying blows to the appliance in accordance with test Ehb of IEC 60068-2-75, the spring hammer test.
The appliance is rigidly supported and three blows, having an impact energy of 0,5 J, are applied to every point of the enclosure that is likely to be weak.
Feature of Spring Hammer Test Apparatus:
The spring hammer consists of three principal parts: the body, the striking element and the release system.
The body comprises the housing, the guide for the striking element, the release mechanism and all rigidly fixed parts.
The striking element comprises the hammer head, the hammer shaft and the cocking knob.
The mass of this assembly is 250 g (200 g) for severities not exceeding 1 J.
Parameter of Spring Hammer Test Apparatus:
| Model | SH-0.5J |
| Impact energy(J) | 0.5 |
| Impact element mass | 250g±5g |
| Overall mass | 1250g±10g |
| Material | Stainless steel |
