| Place of Origin: | China |
| Brand Name: | HongCe |
| Certification: | Calibration Certificate(cost additional) |
| Model Number: | HT-I09 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiatable |
| Packaging Details: | Plywood |
| Delivery Time: | 5 days |
| Payment Terms: | T/T |
| Supply Ability: | 10 Sets per month |
| Product Name: | Test Probe 13 Of IEC 61032 | Usage: | Home Appliance Testing Equipment |
|---|---|---|---|
| Standard: | IEC 60335-1, IEC 61032 | Pin Length: | 15mm |
| Baffle Diameter: | 25±0.2mm | Finger Material: | Stainless Steels |
| Handle Material: | Nylon | Name: | Short Pin Test Probe |
| High Light: | IEC 60335-1 Home Appliance Testing Equipment,Home Appliance Testing Equipment Probe 13 |
||
IEC 60335-1 Home Appliances Testing Equipment Test Probe 13 of IEC 61032
Standard of Electrical Appliance Testing Equipment:
IEC 60335-1: 2020 Household and similar electrical appliances – Safety – Part 1: General requirements clause 8.1.2;
IEC 61032 Protection of persons and equipment by enclosures –Probes for verification figure 9
Application of Test Probe 13 of IEC 61032:
Test probe 13 of IEC 61032 is applied with a force not exceeding 1 N through openings in class 0 appliances, class II appliances and class II constructions, except for those giving access to lamp caps and live parts in socket-outlets.
This pin is intended to verify the protection against access to hazardous live parts in class 0 equipment and class II equipment (see IEC 60536).
Parameter of Test Probe 13:
| Model/ Parameter | HT-I09 |
| Item Name | Short test pin probe |
| Metal pin tip diameter | Ф3 (0, -0.05) |
| Metal pin tail diameter | Ф4 (0, -0.05) |
| Metal pin length | 15 (0, -0.1) |
| Baffle diameter | Ф25±0.2 |
| Baffle thickness | 4 |
| Handle diameter | Ф10 |
| Handle length | 20 |
