| Place of Origin: | China |
| Brand Name: | HongCe |
| Certification: | Calibration Certificate(cost additional) |
| Model Number: | HJ0608A |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiatable |
| Packaging Details: | Plywood |
| Delivery Time: | 40 days |
| Payment Terms: | T/T |
| Supply Ability: | 10 Sets per month |
| Product Name: | Power Cord Flexing Test Apparatus | Usage: | Home Appliance Testing Equipment |
|---|---|---|---|
| Standard: | IEC 60335-1 | Warranty: | 1 Year |
| Flexing Speed: | 0-60cycles/min | Load Voltage: | 0-250V |
| Current Detection: | Judge The Conduction By Current | Load Weight: | 5N,10N |
| High Light: | Power Cord Home Appliance Testing Equipment,One Station Home Appliance Testing Equipment |
||
Flexing Test Apparatus For Power Cord Home Appliance Testing Equipment One Station
Standard of Home Appliance Testing Equipment:
IEC 60335-1 Household and similar electrical appliances – Safety – Part 1: General requirements Clause 23.3 and 25.14.
Application of Home Appliance Testing Equipment:
It is used to check that the supply cord of the small household appliances (such as Coffee pot / electric iron) and lamps is adequately protected against excessive flexing where it enters the appliance.
Test sample of Home Appliance Testing Equipment:
Small home appliances, such as coffee pot, electric iron, toaster, luminaires and etc.
Feature of Home Appliance Testing Equipment:
We can customise to your requirements
The flexing test apparatus is with load, and the load voltage can be customized.
Test parameter like the test cycles, speed, voltage and etc. can be preset on the touch screen.
Parameter of Flexing Test Apparatus:
| Parameters / Model | HJ0608A | HJ0608B | HJ0608C |
| Input Power | AC220V 50HZ | AC220V 50HZ | AC220V 50HZ |
| Control Method | PLC control, touch screen operation | PLC control, touch screen operation | PLC control, touch screen operation |
| Station | One | 3 (can upgrade to 6 stations),synchronous | One |
| Drive Mode | Electrical | Electrical | Electrical |
| Flexing Angle | 0-360°, preset on the touch screen | 0-360°, preset on the touch screen | 0-360°, preset on the touch screen |
| Flexing Speed | 0-60cycles/min, can be preset | 0-60cycles/min, can be preset | 0-60cycles/min, can be preset |
| Test Cycles | 0-999999, can be preset | 0-999999, can be preset | 0-999999, can be preset |
| Loading Weight | 5N,10N | 5N,10N | 5N,10N |
| Loading Voltage | 0-250V, can be regulated | - | 0-250V, can be regulated |
| Sample judgment | Judge the conduction by current | Judge the conduction by current | Judge the conduction by current |
| Specimen fixture | Universal fixtures for small house appliances, 1 set | - |
Universal fixtures for small house appliances, 1 set Universal fixtures for skin & hair care appliances, 1 set |
