IEC60332-1 Flammability Testing Equipment For Vertical Flame Single Cable

IEC60332-1 Flammability Testing Equipment For Vertical Flame Single Cable

Brand Name:	HongCe
Model Number:	VF-1
MOQ:	1 set
Price:	Negotiable
Payment Terms:	L/C, T/T
Supply Ability:	10 set per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Calibration certificate(cost additional)

Product Name:

Electric Wire Flame Resistance Test Apparatus

Warranty:

1 Year

Power:

AC 220V/50HZ

Standard:

IEC60332-1-1, IEC60332-1-2, IEC60332-1-3

Application:

Single Insulated Wire Or Cable

Burner Opening:

Φ7±0.05mm，made Of Brass

Combustion Chamber:

300×450×1200±25mm

Chamber Material:

Stainless Steel

Packaging Details:

Plywood

Highlight:

IEC60332-1 Flammability Testing Equipment

Vertical Flammability Testing Equipment

Single Cable Flammability Testing Equipment

Product Description

IEC60332-1 Flammability Testing Equipment Test For Vertical Flame For Single Cable

Purpose of Flammability Testing Equipment:
The test apparatus for testing the resistance to vertical flame propagation for a single vertical electrical insulated conductor or cable, or optical fibre cable, under fire conditions.

Standard of Flammability Testing Equipment:

IEC 60332-1-1 Tests on electric and optical fibre cables under fire conditions – Part 1-1: Test for vertical flame propagation for a single insulated wire or cable – Apparatus;

IEC 60332-1-2 Tests on electric and optical fibre cables under fire conditions – Part 1-2: Test for vertical flame propagation for a single insulated wire or cable – Procedure for 1 kW pre-mixed flame;

IEC 60332-1-3 Tests on electric and optical fibre cables under fire conditions – Part 1-3: Test for vertical flame propagation for a single insulated wire or cable – Procedure for determination of flaming droplets/particles;

Feature:
This series of products adopt integral type inlet ignition system. The combustion time delays 0.1S thus to make sure the sufficient time of gas burning. They are with matte black background, multi-functional flame measure gauge, stainless steel of box full, large observation window, imported digital indicator of high precision, nice appearance. And they gather a number of advantages of similar products home and abroad.

Parameters of Flammability Testing Equipment:

Working voltage	220V/50-60Hz
Control operation mode	Electrical control, button operation
Blast burner standard	IEC60695-11-2 Annex A, Burner opening:Φ7±0.05mm,made of brass
Gas flow and gas category	Mixture gas: 650±30mL/min propane；10±0.5L/min air,Dual flow meter adjustment
Burning time	9999X0.1S
Burning angle	Tilt 45°±2°, Adjustable
Test flame calibration	Temperature measuring copper head: 500W: Ф9mm±0.01mm, weight before drilling:10 ± 0 .05g
	Thermocouple: The American original Omega φ0.5 armour nickel-chromium/nickel aluminum wire K-Thermocouple, temperature resistance 1100°
	Distance between the bunsen burner port to temperature measuring copper block:95 mm
	Flame height: Inner flame:55±5mm, outer flame:180±10mm
	Temperature rise time from 100±5°C to 700°±3°C 45±5s
Combustion chamber	WDH=300×450×1200±25mm
Gas	>95% propane or coal gas
Test sample	Length: 600±25mm, distance from the bottom:50mm
Fixed horizontal support of the sample	2, distance:550mm
Dimension	WDH=700×450×1350mm, weight about 120kg
