Place of Origin: | China |
Brand Name: | HongCe |
Certification: | Calibration Certificate(cost additional) |
Model Number: | HH0812A |
Minimum Order Quantity: | 1 set |
---|---|
Price: | Negotiation |
Packaging Details: | Plywood |
Delivery Time: | 30 days |
Payment Terms: | T/T |
Supply Ability: | 10 Sets per month |
Name: | Natural Convection Oven | Standard: | IEC60065, IEC60884-1 And Etc. |
---|---|---|---|
Warranty: | 1 Year | Complete Air Changes: | 8-20 Times/hour |
Inner Wall Material: | Stainless Steel | Outer Chamber Material: | Sprayed Cold-rolled |
Max Temperature: | RT+20℃~300℃ | Rotary Motor Power: | 1/4HP |
High Light: | Natural Convection Oven Heating Chamber,IEC 60065 Oven Heating Chamber |
IEC 60065 Natural Convection Oven Heating Chamber Max temp 300℃
Safety ventilation system :
1. There is no built-in circulating air system in the inner chamber to ensure temperature uniformity: 1% (calculated based on the highest temperature);
2. Built-in adjustable ventilation outlet , by changing the size of the outlet, the size of the ventilation volume can be appropriately changed, and the adjustment is very convenient
3. Adjustment range of ventilation volume: 8~20 times/hour. Timer: 999.9 hours can be set. (Optional with power-off hold and automatic power-on function) The air flow meter is used to measure the ventilation flow. IEC Test Equipment
Parameters:
1 | Inner size | 1000*1000*1000mm |
2 | Electric heating power | 5.5KW, with two-stage heating selection mode |
3 | Intelligent PID control, with self-tuning function, instrument accuracy: 0.1 ℃ | |
4 | Temperature uniformity | <2℃ |
5 | Max temperature | RT+20℃~300℃ IEC Test Equipment |
6 | Sample rotation speed | 5~10r.p.m |
7 | Rotary motor power | 1/4HP |
8 | Stainless steel inner wall and outer chamber are cold-rolled and sprayed | |
9 | Double-layer stainless steel compartment, single-layer stainless steel round turntable IEC Test Equipment | |
10 | Natural ventilation rate | 8~20 times/hour |
11 | With ultra-high temperature protection function, it can effectively protect the safety of equipment |
Picture:
