| Place of Origin: | China |
| Brand Name: | HongCe |
| Certification: | TUV、ITS、CSA、BV、SGS 、CNAS(cost additional) |
| Model Number: | HT-PSGG |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiatable |
| Packaging Details: | Aluminum Box |
| Delivery Time: | 10 Days |
| Payment Terms: | T/T, L/C, D/A, D/P, Western Union, MoneyGram |
| Supply Ability: | 100 set/ month |
| High Light: | electric socket tester,electrical plug tester |
||
|---|---|---|---|
VDE0620 Germany Plug Socket Tester , Plug Sockets Stainless Steel Gauges
Standard:VDE0620-1
Material:Stainless Steel
Color:Metallic
Product information:
These measuring gauges confirm to the standard of VDE0620, which are used for the dimensional
measurement and verification of the plug socket for household and similar use.
The specific measuring gauges are included as follows:
|
No. |
Standard |
Description |
quantity |
|
1 |
DIN-VDE0620-1-Lehre1 |
The jack of the socket R gauge (5, 5.8, 6) |
3PCS |
|
2 |
DIN-VDE0620-1-Lehre2 |
The minimum opening width and minimal contact Jack pull-out force |
2 PCS |
|
3 |
DIN-VDE0620-1-Lehre3 |
Bipolar plug insertion force |
1 PC |
|
4 |
DIN-VDE0620-1-Lehre4 |
Double plate plug with earthing contact insertion flanking force |
1 PC |
|
5 |
DIN-VDE0620-1-Lehre5 |
Gauge used to test the first time contact closure interval |
1 SET/4PCS |
|
6 |
DIN-VDE0620-1-Lehre6 |
Pin diameter |
1 SET/4PCS |
|
7 |
DIN-VDE0620-1-Lehre7 |
Pin distance |
1 SET/ 2 IN ONE |
|
8 |
DIN-VDE0620-1-Lehre8 |
The maximum opening width contact jack |
1 PC |
|
9 |
DIN-VDE0620-1-Lehre9 |
The interchangeability of the test plug gauge |
1 PC |
|
10 |
DIN-VDE0620-1-Lehre10 |
Single pole contact hole contacts may not A |
1 PC |
|
11 |
DIN-VDE0620-1-Lehre10 |
Single pole contact hole contacts may not B |
1 PC |
|
12 |
DIN-VDE0620-1-Lehre11 |
No bipolar plug ground contact can not be inserted |
1 PC |
|
13 |
DIN-VDE0620-1-Lehre12 |
The possibility of unipolar insertion plug not (containing 250 grams and 1000 grams of weightand the positioning rack) |
1 SET/4PCS |
|
14 |
DIN-VDE0620-1-Lehre14 |
On both sides of the ground test |
1 PC |
|
15 |
DIN-VDE0620-1-Lehre16a |
Plug the maximum pullout force (16a) |
1 PC |
|
16 |
DIN-VDE0620-1-Lehre16d |
Plug the minimum pullout strength (16d) |
1 PC |
|
17 |
DIN-VDE0620-1-Leher16e |
Gauge |
1 PC |
|
18 |
DIN-VDE0620-1-Lehre17 |
Lehre17 gauge |
1 PC |
|
19 |
DIN-VDE0620-1-Lehre18 |
Lehre18 gauge |
1 PC |
|
20 |
DIN-VDE0620-1-Leher19a |
Gauge |
1 PC |
|
21 |
DIN-VDE0620-1-Leher19b |
Gauge |
1 PC |
|
22 |
DIN-VDE0620-1-Bild14 |
Bild14 gauge |
1 SET |
|
23 |
DIN-VDE0620-1-Bild43 |
Bild43 gauge |
1 SET / 2PCS |
