IEC60884-1 Clause 30.1 Figure 41 High Temperature Indentation Device

    • IEC60884-1 Clause 30.1 Figure 41 High Temperature Indentation Device
    • IEC60884-1 Clause 30.1 Figure 41 High Temperature Indentation Device
    • IEC60884-1 Clause 30.1 Figure 41 High Temperature Indentation Device
    • IEC60884-1 Clause 30.1 Figure 41 High Temperature Indentation Device
  • IEC60884-1 Clause 30.1 Figure 41 High Temperature Indentation Device

    Product Details:

    Place of Origin: China
    Brand Name: HongCe
    Certification: TUV、ITS、CSA、BV、SGS 、CNAS(cost additional)
    Model Number: HDX1310

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Packaging Details: Plywood
    Delivery Time: 15 days
    Payment Terms: T/T
    Supply Ability: 15 set per month
    Contact Now
    Detailed Product Description
    Blade Width: 0.70±0.01mm Sample Support Plane: 0°、90°,120°
    Support: Smooth Stainless Steel Support Working Station: Two Stations

    IEC60884-1 Clause 30.1 Figure 41 High Temperature Indentation Device





    Standard:IEC60884-1-2002 clause 30.1 figure 41,IEC60598- 2-20 clause 20.15, EN60811-3-1 insulating and sheathing materials of electric and optical cables-common test methods.

    Application:For PVC insulated and sheathed wire and cable products, measure resistance to thermal deformation of PVC insulated and sheathed under the action of thermal and mechanical load, the insulation wire to be measured can be round, fan-shaped and parallel cord, the sheathed to be measured can be round or flat. It is not recommended to use this test method when the thickness of the test sample (Insulation or sheath) less than 0.4MM.

    Test sample:PVC insulated and sheathed wire and cable products.



    Technical parameters:

    Working station Two stations
    Blade width 0.70±0.01mm
    Sample support plane 0°,90°,120° one piece per each,can replaceable use
    Support Smooth stainless steel support
    The load weight is composed of a rectangular knife + weight +tray), rectangular knife and tray are 120g, and equip with two sets of a standard weight of 1~1kg.



    The specimens are tested by means of the apparatus shown in figure 41. This apparatus has a rectangular blade (see figure 41a) with an edge 0.7 mm wide, to be used in the case of round pins, or a blade having a round shape (see figure 41 b), with a diameter of 6 mm and an edge of 0.7 mm, in other cases.

    The specimens are placed in position as shown in figure 41. The force applied through the blade is 2.5 N. The apparatus, with the specimen in position, is maintained for 2 h in a heating cabinet at a temperature of (200±5)℃.

    The specimen is then removed from the apparatus and, within 10 s, cooled by immersion in cold water. The thickness of the insulation remaining at the point of impression is measured and shall not have been reduced by more than 50% of its original value measured at the start of the test.

    IEC60884-1 Clause 30.1 Figure 41 High Temperature Indentation Device
