IEC 60884-1 Tumbling Barrel Testing Machine 5rpm 10 Time Per Min

IEC 60884-1 Tumbling Barrel Testing Machine 5rpm 10 Time Per Min

IEC 60884-1 Tumbling Barrel Testing Machine 5rpm 10 Time Per Min
IEC 60884-1 Tumbling Barrel Testing Machine 5rpm 10 Time Per Min
IEC 60884-1 Tumbling Barrel Testing Machine 5rpm 10 Time Per Min
Product Details:
Place of Origin: China
Brand Name: HongCe
Certification: calibration certificate (cost additional)
Model Number: HC9922
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiatable
Packaging Details: plywood
Delivery Time: 30 days
Payment Terms: T/T
Supply Ability: 10 set /month
Contact Now
Detailed Product Description
Name: Tumbling Barrel Testing Machine Standards: IEC60884-1, IEC60068-2-31, EN50075
Application: Plug And Socket Rotate Speed: 5rpm
Drop Rate: 10time Per Min Test Times: 0~9999
Drop Height: 500mm (1000mm For Option) Barrel Number: Single Barrel
High Light:

IEC 60884-1 Tumbling Barrel Testing Machine

,

5rpm Tumbling Barrel Testing Machine

,

10 Time / Min Tumbling Barrel Testing Machine

IEC 60884-1 - Tumbling Barrel Testing Machine - 5rpm / 10time Per Min



IEC 60884-1 2013 clause 24.2:

The specimens are individually subjected to the test Ec:Rough handling shocks, primarily for equipment-type specimens, procedure 2 of IEC 60068-2-31, the number of falls being
– 1 000 if the mass of the specimen without flexible cable does not exceed 100 g,                                  Plug Socket Tester
– 500 if the mass of the specimen without flexible cable exceeds 100 g, but does not exceed 200 g, and
– 100 if the mass of the specimen without flexible cable exceeds 200 g.
The barrel is turned at a rate of five revolutions per minute, 10 falls per minute thus taking place.
After the test, the specimens shall show no damage within the meaning of this standard. In particular,
– no part shall have become detached or loosened;                                  Plug Socket Tester
– the pins shall not have become so deformed that the plug cannot be introduced into a socket-outlet complying with the relevant standard sheet and also fails to comply with the requirements of 9.1 and 10.3;
– the pins shall not turn when a torque of 0,4 Nm is applied, first in one direction for 1 min and then in the opposite direction for 1 min.
The shutters of socket-outlets shall be tested again according to Clause 21, from paragraph 19 up to paragraph 24 (only the test of shutters).
NOTE 1 During the examination after the test, special attention is paid to the connection of the flexible cable.
NOTE 2 Small pieces may be broken off without causing rejection provided that the protection against electric shock is not affected.
NOTE 3 Damage to the finish and small dents which do not reduce the creepage distances or clearances below the values specified in 27.1 are ignored.                        Plug Socket Tester





Standard: IEC 60884-1 2013 clause 24.2, IEC 60598-1, IEC 60998.1, VDE0620, IEC 60068-2-31, BS1363.1, EN50075, UL60730, IEC 60312-1 and so on

Application: This device is suitable for test the drop resistance of plugs and socket-outlets, surface type mounting boxes, screw glands, gland covers, switch and other electrical accessories.                       Plug Socket Tester

Test sample: plugs and socket-outlets, surface type mounting boxes, screw glands, gland covers, switch and other electrical accessories.

Feature: This tester can preset test times, automatic stop when set test times completed.



Parameters:

Model HC9922
Rotate speed 5rpm
Drop rate 10time per min
Material Sideways 1.5mm high-quality steel plate, upper and lower for 3mm steel pad in the 10-19mm wood and oblique part slide surface is plastic laminate, with triangle rubber pad
Test times 0~9999                           Plug Socket Tester
Drop height 500mm (1000mm for option)
Barrel number Single or double
Application Plug and socket and similar electrical accessories
Standards IEC60884.1, IEC60068-2-31, EN50075
Power supply 220V 50Hz

IEC 60884-1 Tumbling Barrel Testing Machine 5rpm 10 Time Per Min 0
IEC 60884-1 Tumbling Barrel Testing Machine 5rpm 10 Time Per Min 1
