| Place of Origin: | China |
| Brand Name: | HongCe |
| Certification: | calibration certificate (cost additional) |
| Model Number: | HJ0636C |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiatable |
| Packaging Details: | plywood |
| Delivery Time: | 40 days |
| Payment Terms: | T/T |
| Supply Ability: | 10 set /month |
| Product Name: | Refrigerator Door Endurance Tester | Warranty: | 1 Year |
|---|---|---|---|
| Power Supply: | 220V 50Hz | Standard: | IEC 60335-2-24, IEC 62552 |
| Usage: | Durability And Structural Testing | Revolving Open Close Door Angle: | 0-90°, Can Be Preset |
| Drive Mode: | Servo Motor Drive | Sample Clamping Method: | Vacuum Sucker |
| High Light: | IEC 60335 Electrical Appliance Tester,Clause 11.3 Electrical Appliance Tester,IEC 62552 Refrigerator Door Endurance Tester |
||
IEC60335 Electrical Appliance Tester Refrigerator Door Endurance Tester Touch Screen Operation
Product information:
The refrigerator door endurance tester is special designed and manufactured as per IEC 60335-2-24 clause 22.112, IEC 62552 clause 11.2,clause 11.3 and etc. Suitable for refrigerator repeated opening and closing test (open /close door endurance test);refrigerator drawer endurance test .It is a special equipment for refrigerator doors durability and drawer endurance test .
The equipment adopts advanced PLC intelligent control system, touch screen humanized operation interface to make recording and display more accurate; with preset test times, on current detection, load voltage regulation and display, test speed, test stroke, open / close door pull force setting, pull force transient curve display, test data storage and query, fault alarm and other functions, can be analyzed by the data record whether the test sample is qualified or not. It is the first choice for large metrology institutions and laboratories.
Test Project:
IEC 60335-2-24 clause 22.112
Doors and lids of compartments in appliances test equipment
IEC 62552 clause 11.2 ,clause 11.3
Endurance test for doors ,lids and drawers .
Technical parameters:
| Specimen Range, Use, Principle, Structure And Use Environment | |
| Samples And Limitations | Refrigerating Appliances (Refrigerator) |
| Test Purposes | It is used for endurance life testing of interlocks or guides for refrigerator doors or drawers to verify the reliability of interlocks; also used to assist other tests for repeated door opening and closing operations, such as defrosting test and refrigerant leak test |
| Test Principle | The motor drives the manipulator, driving the door or cover sucked by the Vacuum sucker to reciprocate at a certain speed, to verify the reliability of interlocking device. |
| Structure |
The equipment is divided into an electrical control cabinet (including load voltage regulator), a frame and a robot arm. Size:1500×1300×2200(mm)W×D×H Weight :140kg |
| Operation Environment |
Power supply : AC220V±10%/50-60Hz, power :6KW Air source : 0.5-0.7MPa Compressed air Place Of Use: Atmospheric pressure 80 ~ 106kpa; Ambient temperature 5～40°C; relative humidity(20～80)%RH; No violent shaking, vibration, no electromagnetic interference, no dust, no explosive and corrosive gas, good heat dissipation |
| Performance | |
| Test Station |
Revolving Door Action Position Drawer action station |
| Electrical Control Method | PLC intelligent integrated control, 7-inch human-machine touch interface operation |
| Drive Mode | Servo motor drive |
| Sample Clamping Method | Vacuum sucker |
| Open/Close Door Speed |
Revolving Door Action: 0-360°/s(1.5m/s), can be preset Drawer action: 0-100mm/s, can be preset |
| Revolving Open Close Door Angle | 0-90°, can be preset |
| Drawer Door Opening Distance | 0-100mm, can be preset |
| Test Times | 0-999999 times , can be preset |
| Load Voltage | 0-250V, adjustable |
| Test Item And Crafting Process |
1. Refrigerator door interlock device endurance test Process: Vacuum sucker automatic suck the door---- Open the door to a preset angle at a preset speed(45°)---- close the door at preset speed---- Repeatedly open and close the door until reaches the test times 2. Refrigerator drawer door endurance test Process: Vacuum sucker automatic suck the door---- Open the drawer to the preset distance at a preset speed(15-25mm)----Close drawers at preset speed----Repeatedly open and close the drawer until reaches the test times |
| Safety Protection Device | |
| Power | Leakage protection, overload and short circuit protection |
| Motor | Overload, short circuit protection |
