ISO9906 Water Pump Comprehensive Performance Test System 0 - 3000 Rpm

ISO9906 Water Pump Comprehensive Performance Test System 0 - 3000 Rpm

ISO9906 Water Pump Comprehensive Performance Test System 0 - 3000 Rpm
video
ISO9906 Water Pump Comprehensive Performance Test System 0 - 3000 Rpm
Product Details:
Place of Origin: China
Brand Name: HongCe
Certification: calibration certificate (cost additional)
Model Number: HCWP300
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiatable
Packaging Details: plywood
Delivery Time: 40 days
Payment Terms: T/T
Supply Ability: 1 set /month
Contact Now
Detailed Product Description
Product Name: Water Pump Comprehensive Performance Test System Power Supply: 220V 50Hz
Rotating Speed(r/min): 0-3000rpm Flow Rate (M³/h): 0-200M³/h
Drive Mode: Servo Motor Drive Pump Head(m): 0-200m
Water Circulatory System: Open Style Pipe Diameter: 1 Inch, 2 Inch, 3 Inch, 4 Inch, Total 4 Lines Pipe Diameter
High Light:

3000 Rpm Comprehensive Performance Test System

,

200M3/h Comprehensive Performance Test System

Water Pump Comprehensive Performance Test System 0 - 3000 rpm



Standard:

ISO9906 Rotodynamic pumps - Hydraulic performance accetance tests - Grades 1, 2 and 3.



Application:

This pump performance comprehensive test system is a special system for pump performance testing, suitable for various test pump types; the system is mainly composed of main control cabinet, flow sensor, pressure sensor and instrument. The pump motor can be tested for voltage, current, power, flow, speed, pressure, head and other data; and can draw H-Q curve, P-Q curve, η-Q curve and (NPSH) according to the data collected by the test project. ) r-Q curve. Appliance Performance Test Lab



Parameters:



Basic parameter requirement

medium Clear water
Test pump type

Centrifugal pump

Mixed flow pump

Axial flow pump

Whirlpool pump

Screw pump

Well submersible pump

Sewage submersible pump

Small submersible pump

Fire pump

Voltage(V) 0-500V
power(KW) 200
Rotating speed(r/min) 0-3000rpm
Flow rate(M³/h) 0-200M³/h
Pump head(m) 0-200m









System Requirements

water circulatory system open style
Pipe diameter 1 inch, 2 inch, 3 inch, 4 inch, total 4 lines
Traffic regulation Electric
Shaft power flow method Electrometry
Test items Flow rate, pump total head, speed of rotation, pump power input, cavitation test
System accuracy Level 2 / Level C
Acquisition parameters AC voltage, current, power, frequency, motor speed, inlet pressure, outlet pressure, flow, etc.
Pump performance analysis and calculation of main parameters, curves Head, flow, NPSH; flow at rated head, lift at rated flow, pump measured flow deviation, head deviation, pump efficiency deviation, and so on.
Data Acquisition Analysis Mode Computer automatic collection, analysis, printing, database management



ISO9906 Water Pump Comprehensive Performance Test System 0 - 3000 Rpm 0

ISO9906 Water Pump Comprehensive Performance Test System 0 - 3000 Rpm 1
