Heat Exchanger Vacuum Chamber Helium Leak Detection System 1g/a Leakage Rate 6min/pc

Heat Exchanger Vacuum Chamber Helium Leak Detection System 1g/a Leakage Rate 6min/pc

    • Heat Exchanger Vacuum Chamber Helium Leak Detection System 1g/a Leakage Rate 6min/pc
    • Heat Exchanger Vacuum Chamber Helium Leak Detection System 1g/a Leakage Rate 6min/pc
    • Heat Exchanger Vacuum Chamber Helium Leak Detection System 1g/a Leakage Rate 6min/pc
    • Heat Exchanger Vacuum Chamber Helium Leak Detection System 1g/a Leakage Rate 6min/pc
  • Heat Exchanger Vacuum Chamber Helium Leak Detection System 1g/a Leakage Rate 6min/pc

    Product Details:

    Place of Origin: Made in China
    Brand Name: HongCe
    Certification: CE, Ross, FCC(cost additional)
    Model Number: HJ053

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: Customized
    Packaging Details: Plywood
    Delivery Time: 3 months
    Contact Now
    Detailed Product Description
    Test Workpiece: Heat Exchanger Leak Rate: 1g/a
    Test Cycle: 6min/pc Gas For Fine Leakage Detection: Helium
    Pressure For Fine Leakage Detection: 4.0Mpa Helium Recovery: ≥98%

    Vacuum Chamber Helium Leak Detection System for Heat Exchanger



    This helium leak test equipment is made according to the base working principle: helium as a tracer gas, the workpiece will be filled with helium in the vacuum chamber, and then through a helium leak detector leak can quickly and accurately determine the accuracy of the workpiece’s leakage.

    Heat Exchanger Vacuum Chamber Helium Leak Detection System 1g/a Leakage Rate 6min/pc

    Main Techincal Parameters:



    Test Workpiece Heat Exchanger
    Vacuum Chamber 1
    Vacuum Chamber Dimension According to the actual workpiece dimension, no more than 1300L
    Number of Workpiece per Chamber 1
    Workpiece Connection Method Fixture positioning, joint sealing
    Leakage Rate 1g/a
    Test Cycle 6min/pc (Time from chamber door closed to opened)
    Gas for Gross Leakage Detection Nitrogen
    Pressure for Gross Leakage Detection 4.0Mpa (Downwards adjustable)
    Gas for Fine Leakage Detection Helium (>99.99%)
    Pressure for Fine Leakage Detection 4.0Mpa (Downwards adjustable)
    Connection between Workpiece and Vacuum Chamber The operator plugs one end of the workpiece with a special plug, and seals the other end of the workpiece with a special connector. After the workpiece is transferred into the vacuum chamber, the special sealed male connector of the workpiece is connected to the quick female connector in the vacuum chamber.
    Helium Recovery Automatic recycling system, helium recovery rate≥98%

    Work Processes Chart:
    Heat Exchanger Vacuum Chamber Helium Leak Detection System 1g/a Leakage Rate 6min/pc

    Wokpiece is connected by a fast coupler shown as below:

        Heat Exchanger Vacuum Chamber Helium Leak Detection System 1g/a Leakage Rate 6min/pc
